Pivot Cycles Shadowcat Ride SLX/XT w/Alloy Wheels 2024
Details
SHADOWCAT? YES, SHADOWCAT.
Lithe, agile, sharp, fast and fun, the Shadowcat is a trail-carving expression of blazing speed and feline creative mayhem. Pivot’s latest offering capitalizes on the acceleration and responsiveness of 27.5" wheels and acclaimed dw-link suspension to bring to life a bike that offers transformative capability for riders of every stripe.
PRODUCT DETAILS
Get everything you need to know about the Shadowcat.
- Ultra-Light Hollow Core Carbon Frame.
- Class-Leading Strength to Weight Ratio.
- Seamlessly Integrated Headset Cups save weight and ensure easy service.
- Excellent Standover height for all sizes.
- Custom tuned Fox Live Valve builds allow for layers of tuning to allow for a plusher than plush feel unmatched by any other suspension setup.
- 140mm of supple-yet-efficient dw-link suspension travel featuring a vertically mounted trunnion metric air shock.
- Equipped with a 44mm offset 160mm-travel Fox 36 fork.
- Agile and playful 27.5" wheels with tires up to 2.6"
- Long and low modern geometry for a confident ride.
- Short 430mm Chainstays for snappy cornering.
- Large Water Bottle Clearance on all sizes.
- Pivot Tool Dock system compatible with mounts under the top tube and integrated into the underside of the frame.
- Hassle free full internal routing with Pivot cable port system.
- Featuring the easy to find UDH rear derailleur hanger for peace of mind when traveling the world.
| Size | X-Small | Small | Medium | Large |
|---|---|---|---|---|
| Seat Tube Length (C-T) (cm) | 34.3 | 36.8 | 39.4 | 43.2 |
| Top Tube Length (cm) | 56.9 | 59.5 | 62.7 | 65 |
| Head Tube Length (cm) | 8.5 | 11 | 12 | 13 |
| Head Tube Angle | 65.8° | 65.8° | 65.8° | 65.8° |
| Seat Tube Angle (Eff.) | 76° | 76° | 76° | 76° |
| Chainstay Length (cm) | 43 | 43 | 43 | 43 |
| Bottom Bracket Height (cm) | 34 | 34 | 34 | 34 |
| Bottom Bracket Drop (cm) | 1.7 | 1.7 | 1.7 | 1.7 |
| Standover Height (cm) | 62.4 | 63.8 | 65.7 | 67.1 |
| Wheelbase (cm) | 114.2 | 117.2 | 120.6 | 123 |
| Stack (cm) | 58.2 | 60.5 | 61.4 | 62.3 |
| Reach (cm) | 41 | 43 | 46 | 48 |
- Frame: Shadowcat - Carbon
- Wheels Size: 27.5"
- Rear Shock: Fox Factory Float DPS
- Fork: Fox Performance 36 27.5", 44mm offset, FIT4 - 160mm
- Headset: Pivot precision sealed integrated cartridge
- Rear Derailleur: Shimano XT M8100 SGS 12-Speed
- Cassette: Shimano SLX M7100 10-51t
- Shifters: Shimano SLX M7100 ISPEC EV 12-Speed
- Brakes: Shimano SLX M7120 4-piston
- Crankset: Raceface Ride 32t
- Handlebar: Phoenix Race Low Rise Aluminum - 780mm
- Grips: Phoenix Factory lock-on
- Stem: Phoenix Team Enduro / Trail
- Seatpost: Fox Transfer Performance Elite 125mm (XS), SDG TELLIS 150mm (SM), Fox Transfer Performance Elite 175mm (MD-LG)
- Saddle: Phoenix WTB Pro High Tail Trail (XS, SM), Phoenix WTB Volt Pro (medium width) (MD-XL)
- Wheels: DT Swiss M1900 w/ DT Swiss 370 hub, 30mm - 27.5” 15x110 F/12x148 R
- 15x110 F/12x148 R
- Wheel Material: Alloy
- Front Tire: Maxxis Dissector 27.5" x 2.4" TR, EXO
- Rear Tire: Maxxis Dissector 27.5" x 2.4" TR, EXO
- Brake Rotors: Shimano SLX 6-bolt - 180mm
- Chain: Shimano CN-M7100 12-Speed
